A curated catalogue of human genomic structural variation




Variant Details

Variant: esv8296



Internal ID9605564
Landmark
Location Information
TypeCoordinatesAssemblyOther Links
Innerchr5:7610735..7610805hg38UCSC Ensembl
Outerchr5:7610700..7610853hg38UCSC Ensembl
Innerchr5:7610848..7610918hg19UCSC Ensembl
Outerchr5:7610813..7610966hg19UCSC Ensembl
Innerchr5:7663848..7663918hg18UCSC Ensembl
Outerchr5:7663813..7663966hg18UCSC Ensembl
Cytoband5p15.31
Allele length
AssemblyAllele length
hg38154
hg19154
hg18154
Variant TypeCNV gain
Copy Number
Allele State
Allele Origin
Probe Count
Validation Flag
Merged StatusM
Merged Variants
Supporting Variantsessv30737
Samples
Known GenesADCY2
MethodSequencing
AnalysisWe detected SVs based on span size and orientation information of each paired-end read. Paired-end reads with an anomalously long span size (more than double the average span size of each DNA library) were identified as SV candidates (deletion and inversion), especially when they had a minimum of three reads in the region, maximum 100 read depth and mapping quality (Q20). SV candidates either found in repeat regions of the genome or having more than 100 kb of genomic deletions were filtered out. For insertion detection larger than the short indels (-29 to +14 bp), the longest 300-bp span size of our paired-end libraries was used. Thus, we could fill 175-bp to 250-bp insert gaps between short inserts and large inserts. The criteria used for detecting these insertions absent from the reference genome in the range of 175-250 bp were minimum four read depth, maximum 60 read depth to filter out randomly placed hits in a repetitive structure region, and mapping quality (Q20).
PlatformIllumina Genome Analyzer
Comments
ReferenceAhn_et_al_2009
Pubmed ID19470904
Accession Number(s)esv8296
Frequency
Sample Size1
Observed Gain0
Observed Loss0
Observed Complex0
Frequencyn/a
